PG Plus 100 FID Tower Hydrogen Generator

The space-saving PG Plus 100 FID Tower Hydrogen Generator uses the latest proton exchange membrane (PEM) technology to produce pure hydrogen.

De-ionized water is automatically loaded from smart internal system tanks with a 3 liter capacity, providing up to 3000 liters of H2 before a refill is required. The only recommended maintenance is replacement of the internal deionizing cartridge, which has been greatly simplified.

PG PLUS 100 FID TOWER FEATURES:
▪︎ Flow rate 100 mL/min
▪︎ Purity >99.9996%
▪︎ Pressure up to 11 barg (160 psig)
▪︎ Unique patented membrane drying system
▪︎ Proprietary 100% titanium cell technology
▪︎ USB connectivity
▪︎ 2 year standard warranty

View Product Brochure

Part# DB-FTHG100-EU (230-240V/50-60Hz)
Part# DB-FTHG100-US (115V/60Hz)
Part# DB-FTHG100-JP (100V/60Hz)

GC APPLICATIONS
▪︎ GC-FID FUEL GAS
▪︎ GC-FPD FUEL GAS
▪︎ GC-NPD PLASMA GAS

ANALYZER APPLICATIONS
▪︎ TOTAL HYDOCARBON ANALYZER (THA) FUEL GAS

▪︎ HYDROGEN REACTORS
▪︎ HYDROGEN FUEL CELLS

The following options are available:
▪︎ Zero Air Option 1.8 L/min or 5 L/min
▪︎ I/O board
▪︎ Remote control software (RS232 or USB)
▪︎ Cascading hardware (standard or high purity)
▪︎ H2 Sensor
